SteveG Posted September 24, 2006 Share Posted September 24, 2006 picked up a viair 100% duty air compressor, 450C complete with onboard air kit. Fitted it earlier this week. took longer for me to do than expected. More down to finding right location and getting some extra fittings. The compressor is dust and moisture resistant but not waterproof so I decided to fit it inside. I had an arb compressor in the back of the hybrid and found that it got in the way so this time I fitted it behind the drivers seat. I also fitted the guage and on-off switch there too to keep all power cables as short as possible. The compressor draws max of 19A. I located the tank under the drivers seat as the TD5 has it's fuel tank at the rear. I replaced the standard 6mm compression fitting with right angle push-on types. I find these easier to work on and the right angle put less strain on pipe. It tucks up out of the way well, but I think I'll replace the drain plug with a blanking plug so that it doesn't get ripped off.. Having the guage nearby meant that wiring was simple. Unfortunately the lead hose fitted to compressor was not long enough to reach the tank so I got some 8mm push-on fittings and 8mm pipe to extend it.. I also fitted the female output fitting here too. This allows easy access via drivers door or I can also pull it through passenger door and reach both nearside tyres. Again, keeping everthing in one place kept plumbing to short runs.. When I get a rear locker I'll change out combined pressure switch/relay to an 85-105 psi one. The current one is 150psi and it's a straight swap. Cheers Steve Quote Link to comment Share on other sites More sharing options...
JST Posted September 24, 2006 Share Posted September 24, 2006 Steve thats looks like a cracking job, well done very mneat and tidy certianyl not a JST affair! i would consider something for the tank though and as you righly say the drain tap would benefit a change! incase it in some protection folded sheets etc. whats the CFM on that then will it run an impact wrench? Quote Link to comment Share on other sites More sharing options...
landrover598 Posted September 24, 2006 Share Posted September 24, 2006 Done a very tidy job there B) I bet it doesn't leak as much as my newly installed on board air system though Quote Link to comment Share on other sites More sharing options...
SteveG Posted September 24, 2006 Author Share Posted September 24, 2006 Steve thats looks like a cracking job, well done very mneat and tidy certianyl not a JST affair!i would consider something for the tank though and as you righly say the drain tap would benefit a change! incase it in some protection folded sheets etc. whats the CFM on that then will it run an impact wrench? CFM is 1.66 at 0psi and 0.72 at 150 psi. Wit the tank I would think that you could run an impact wrench on burst no problem. Personally I have had one of these for the past few years so I've had no need ... Cheers Steve Quote Link to comment Share on other sites More sharing options...
simonr Posted September 24, 2006 Share Posted September 24, 2006 Well done Steve. When you come to fit lockers - why not leave your pressure switch as is and add a small in line regulator to regulate down to 85psi or so. That way you are getting an effective 50% increase in the capacity of your air tank and the reg will prob cost less than a new switch. (that's what I've done incidentally) Si Quote Link to comment Share on other sites More sharing options...
SteveG Posted September 24, 2006 Author Share Posted September 24, 2006 Well done Steve. When you come to fit lockers - why not leave your pressure switch as is and add a small in line regulator to regulate down to 85psi or so. That way you are getting an effective 50% increase in the capacity of your air tank and the reg will prob cost less than a new switch.(that's what I've done incidentally) Si Good idea Si, i'll source one of those then Thanks Steve Quote Link to comment Share on other sites More sharing options...
white90 Posted September 24, 2006 Share Posted September 24, 2006 you could fit a TDI tank guard to protect the air reservoir Quote Link to comment Share on other sites More sharing options...
SteveG Posted September 24, 2006 Author Share Posted September 24, 2006 you could fit a TDI tank guard to protect the air reservoir Once I fit the blank, I'm not sure it will need it but I'll have to see. Quote Link to comment Share on other sites More sharing options...
Les Brock Posted September 24, 2006 Share Posted September 24, 2006 Steve, The tank will need draining quite regulary, mine have little push type valve, and its surpising how much condensate sits in the tank, a good eggcup full after a weekends use not only will it rust your tank (eventually ) but find its way into your tools/tyres etc Quote Link to comment Share on other sites More sharing options...
davidlandy Posted September 25, 2006 Share Posted September 25, 2006 what about an ARB compressor, does this need emptying as well? I have never done this with mine! Quote Link to comment Share on other sites More sharing options...
white90 Posted September 26, 2006 Share Posted September 26, 2006 I just release the air when not inuse that'll help keep condensation at bay Quote Link to comment Share on other sites More sharing options...
cols110 Posted September 26, 2006 Share Posted September 26, 2006 Very nice mate, this is one of my next jobs on the list, where did you get all the gear, it is the same as Matt Savage sells. The only thing that would worry me a little is the blue air line, it looks a bit small to allow max flow from the tank, especially when you want a high flow rate for blowing tyres etc, the in-side would be fine as it is more than big enough for the supply from the compressor, and for the gauge, but may restrict the flow from the tank. Quote Link to comment Share on other sites More sharing options...
Hybrid_From_Hell Posted September 26, 2006 Share Posted September 26, 2006 Nice job Steve. To proterct it quickly ands simply how about a early type southdown petrol tank guard ? Nige Quote Link to comment Share on other sites More sharing options...
Tonk Posted September 26, 2006 Share Posted September 26, 2006 was the reservoir part of the kit or did u source that separately? Quote Link to comment Share on other sites More sharing options...
SteveG Posted September 26, 2006 Author Share Posted September 26, 2006 Very nice mate, this is one of my next jobs on the list, where did you get all the gear, it is the same as Matt Savage sells.The only thing that would worry me a little is the blue air line, it looks a bit small to allow max flow from the tank, especially when you want a high flow rate for blowing tyres etc, the in-side would be fine as it is more than big enough for the supply from the compressor, and for the gauge, but may restrict the flow from the tank. Yes it is, for some reason the 1007 100% duty kit is a lot lower in price on website only 24 pounds more than compressor on it's own The 6mm tube should be ok as it's universally used for pneumatic applications, but it's easy to change fittings as I did. Just get 1/4 BSP fittings with either 8mm or 10mm pipes. 8 & 10 are used in workshops/factories to feed airlines around so must be ok for air tool applications. Tonk yes tank came with kit, it's a 2.5 Gallon (US) tank. Cheers Steve Quote Link to comment Share on other sites More sharing options...
Tonk Posted September 26, 2006 Share Posted September 26, 2006 i was just looking for ideas for a bigger reservoir and thought yours looked about the right size. do they do chrome ones? Quote Link to comment Share on other sites More sharing options...
SteveG Posted September 26, 2006 Author Share Posted September 26, 2006 i was just looking for ideas for a bigger reservoir and thought yours looked about the right size. do they do chrome ones? I'm surprised they don't as they do chrome and pewter compressors!! The low riders in the US like these for their air suspension. The tanks can be bought on their own and range from 25 pounds up to 67 for the 5 gallon one. Cheers Steve Quote Link to comment Share on other sites More sharing options...
Tonk Posted September 26, 2006 Share Posted September 26, 2006 The tanks can be bought on their own and range from 25 pounds up to 67 for the 5 gallon one.Cheers Steve ooo so they do, cheers Quote Link to comment Share on other sites More sharing options...
white90 Posted September 28, 2006 Share Posted September 28, 2006 would a small airless compressor run from an inverter be another possible option? Quote Link to comment Share on other sites More sharing options...
